Slow Motion & High-Speed Cameras | Aerospace & Industrial Video

Q: What frame rates are available?

Depending on the model, from 120 fps up to 960 fps (and higher on request). Higher frame rates may reduce resolution; we’ll size a system to your target event duration and detail.

Q: Will it work with my SDI recorder or NVR?

Yes. Systems are available with HD-SDI/3G-SDI or IP streaming so you can record on broadcast/military DVRs or network recorders.

Q: Is it suitable for helicopter hoist training or SAR?

Absolutely—high-fps capture enables frame-by-frame review of hook, cable, and aircraft motion to improve safety and procedures.

Q: Are lenses interchangeable?

Yes. C/CS-mount optics provide a wide choice of focal lengths—from ultra-wide to long-range telephoto.

Q: Can you supply a complete kit?

Yes. We can deliver camera, recorder, quick-disconnect cabling, and mounts as a turnkey package aligned to your integration and power standards.

Key Features

Images Coming Soon!

Contact Us About This Product

Camera 1:

Model: BW-CAM-10K
Resolution: 1.2 Megapixels or better
Frames Per Second: Up to 10,860 fps or better
Sensor: CMOS with Correlated Double Sampling and Global Shutter
Pixel Size: 18 um
Sensor Size: 23 x 17.2 mm
Bit Depth: 12 bit
Connectivity: Gigabit Standard Ethernet, RJ-45 Ethernet Port
Timecode: Irig-B Modulated and un-modulated
Power Port: Fischer 6-pin
Video Ports: 3G-SDI and HDMI
Ports: Trigger and Timecode in Dedicated BNC ports, 2 programmable I.O BNC Ports
RAM: 72GB
Power: 100-240VAC with 80W power supply included
Lens Mount: F-Mount

Camera 2:

Model: BW-CAM-1K
Resolution: 4 Megapixels or better
Frames Per Second: Up to 1,100 fps or better
Sensor: CMOS with Global Shutter
Pixel Size: 10 um
Sensor Size: 25.6 x 16 mm
Bit Depth: 12 bit
Connectivity: Gigabit Standard Ethernet, RJ-45 Ethernet Port
Timecode: Irig-B Modulated and un-modulated
Power Port: Fischer 6-pin
Video Ports: 3G-SDI and HDMI
Ports: Trigger and Timecode in Dedicated BNC ports, 2 programmable I.O BNC Ports
RAM: 72GB
Power: 100-240VAC with 80W power supply included
Lens Mount: F-Mount

Overview

Bad Wolf Technologies’ slow-motion / high-speed camera solutions are built for moments you can’t afford to miss. These systems capture at extremely high frame rates so you can replay events in smooth, clear slow motion for training, testing, surveillance, aerospace evaluation, ballistics, industrial inspection, and accident reconstruction. Unlike consumer high-speed gear, they’re rugged and integration-ready—delivering stable performance on helicopters, vehicles, vessels, ranges, and lab rigs with outputs that drop into HD-SDI or IP recording workflows, telemetry, and DAQ systems. Configurable sensors, optics, power, and mounts let you tailor frame rate, resolution, and field-of-view to the mission.

Camera 1:

Model: BW-CAM-10K
Resolution: 1.2 Megapixels or better
Frames Per Second: Up to 10,860 fps or better
Sensor: CMOS with Correlated Double Sampling and Global Shutter
Pixel Size: 18 um
Sensor Size: 23 x 17.2 mm
Bit Depth: 12 bit
Connectivity: Gigabit Standard Ethernet, RJ-45 Ethernet Port
Timecode: Irig-B Modulated and un-modulated
Power Port: Fischer 6-pin
Video Ports: 3G-SDI and HDMI
Ports: Trigger and Timecode in Dedicated BNC ports, 2 programmable I.O BNC Ports
RAM: 72GB
Power: 100-240VAC with 80W power supply included
Lens Mount: F-Mount

Camera 2:

Model: BW-CAM-1K
Resolution: 4 Megapixels or better
Frames Per Second: Up to 1,100 fps or better
Sensor: CMOS with Global Shutter
Pixel Size: 10 um
Sensor Size: 25.6 x 16 mm
Bit Depth: 12 bit
Connectivity: Gigabit Standard Ethernet, RJ-45 Ethernet Port
Timecode: Irig-B Modulated and un-modulated
Power Port: Fischer 6-pin
Video Ports: 3G-SDI and HDMI
Ports: Trigger and Timecode in Dedicated BNC ports, 2 programmable I.O BNC Ports
RAM: 72GB
Power: 100-240VAC with 80W power supply included
Lens Mount: F-Mount

Specification	Value
Available Frame Rates	120 fps, 240 fps, 480 fps, 960 fps (model dependent)
Maximum Resolution	Up to 1080p (1920×1080) or 720p (1280×720) depending on fps
Sensor Type	High-speed CMOS (global-shutter recommended; rolling-shutter optional)
Electronic Shutter	Adjustable; down to 1/10,000 s or faster (model dependent)
Video Outputs	HD-SDI / 3G-SDI / HDMI; IP streaming (RTSP, ONVIF) options
Recording Compatibility	HD DVRs, airborne recorders, solid-state recorders, IP NVRs
Lens Mount	C/CS mount (other mounts available on request)
Field of View	Configurable by lens; ultra-wide to telephoto options
Power Input	12–24 VDC (system dependent)
Form Factor	Ruggedized housings for vehicle/airborne/lab integration
Typical Use Cases	Aerospace test & evaluation, hoist training, ballistics, industrial motion analysis, incident review

Request More Information

Fill out the contact form below and we will reach out to you shortly.

Why Choose This Camera

Frame-accurate insight: High-fps capture reveals motion you can’t see in real time—ideal for training, troubleshooting, and proof-of-performance.
Rugged & integration-ready: Designed for real-world deployment on aircraft, vehicles, marine platforms, and test fixtures—not just lab benches.
Drop-in workflows: SDI and IP options pair with pro recorders, NVRs, and mission systems you already use.
Right tool for the job: Global-shutter sensor options eliminate rolling artifacts; customizable optics match any FOV.
Configurable systems: Power, cabling, mounts, and storage can be tailored to your environment and procedures.
