HD NANO Bullet Camera - BW-CAM-NANO HDSDI 19mm
1/2.8” 2.48 Megapixel, SONY IMX327 Color CMOS sensor and Eyenix DSP
Full HD: 3G-SDI/HD-SDI 1080p60/p30 camera
Simultaneous High Definition & Composite outputs
OSD controller built into the camera harness
Rated to IP67 standard (water/weather/dustproof)
7 lens options, from 20 to 130 degrees FOV
Control Exposure, White Balance, DNR, Day & Night mode
Image manipulation, Mirror, Flip, De-Fog, Motion Detection and more
Contact Us About This Product
View HD NANO Bullet Camera Technical Spec Sheet
HD NANO Bullet Camera Product Overview
The HD NANO 19mm bullet camera is the smallest “micro bullet” style camera available on the market today. Bad Wolf Technologies HD NANO micro bullet camera is designed around the 1/2.8" SONY CMOS sensor (IMX327) and utilizes the most advanced Eyenix DSP (digital signal processor). HD NANO 19mm micro bullet has excellent lowlight/night mode and superior daytime performance. Pictures looks crystal clear, and the colors "pop." HD NANO also complies with 3G-SDI SMPTE 424M (1080p60/p50), HD-SDI SMPTE 292M (1080p30/p25) and 1.0 Vp-p 75Ω RS170 and CVBS NTSC/PAL standards.
The HD NANO micro bullet supports high resolution video up to 1080p60/p50 (3G-SDI), yet it still is capable of outputting CVBS (analog) NTSC/PAL and RS170 signal at the same time. Due to its miniature size and unparalleled performance, the HD NANO is suitable for use in Drones and UAV, flight testing, General and Military Aviation, Defense, Automotive, SAR, Lift and Hoist, Industrial, Surveillance, CCTV, Medical and other applications equally well. Because it handles shock and vibration with ease, the HD NANO is a perfect solution for fixed wing and rotorcraft installations.
Bottom line is that using the most advanced technology on the market, the HD NANO high definition 19mm micro bullet camera outperforms the competition many times its’ size.
PLEASE NOTE: Custom length video/power cable in single shielding is available for the HD NANO Quick Disconnect.
The HD Nano offers full 1080p60 and 1080p30 resolution while being the smallest 3G-SDI and HD-SDI bullet style camera available on the market. The HD Nano is designed to be compact and rugged enough for many applications. 3G-SDI / HD-SDI Video Output can be connected to any 3G-SDI, EX-SDI, HD-SDI or SDI monitor or DVR. Secondary video output provides analog RS170, CVBS NTSC and PAL video. Analog "video out" may be connected to an analog monitor or a DVR "video in" port.
A wide-angle lens if optimized for mobile applications providing a wide view without large amounts of distortion or fisheye effect.
Lens Options:
* 2.9 (please call), 3.7, 6.0, 8.0, 12, 16 mm
Features at a glance:
* Resolution up to 1060p (3G-SDI / EX-SDI).
* Resolution and Frame Rate 1080p60/p50, 1080p30/p25, 720p60/p50 and 720p30/p25.
* 3G-SDI / EX-SDI / HD-SDI / analog RS170 and CVBS NTSC & PAL Video Out.
* RUGGED, waterproof to IP67, Compact (19mm x 56mm), Lightweight (80 grams with wiring harness).
1/2.8″ Sony 2.48 Megapixel Progressive Scan IMX327 CMOS sensor offers 1945(H) x 1109(V) resolution along with excellent low light performance, noise and vibration reduction and more.
HD NANO video settings have been specifically optimized to provide ultimate performance for aviation applications. It also comes with the OSD "joystick" type controller should the need arise to change the factory settings.
Video is output through a BNC connector (HD-SDI) or the Hirose LF series connector (Optional) which contains NTSC/PAL and power input pins. An adjustment toggle on the cable allows you to access the on-screen menu for easy setting changes.
